Welcome to PCB-Investigator

Benefit as developer – both in HW and SW development – from PCB-Investigator’s various features ranging from basic functions to helpful analyses.

Concerning EMC and Hazard Analysis PCB-Investigator supports you with automated length and distance calculations and visualizes the results both as text and graphically. Like that, unnecessary disturbances in the end product can be avoided easily.

Change tracking, which is is especially helpful in your communication with designers, is integrated efficiently with both a net and a component based Compare Plug-In.

A detailed and accurate documentation of all relevant data - with our Design Report Plug-In - in combination with the Embedded Function avoids expensive misunderstandings.

In the assembly, a variety of possibilities for simplifying your workflow can be found in PCB-Investigator:

Prepare test adapter data for a Testpoint analysis or avoid any possibility of problems in fabrication with a Component and Tombstone Check. PCB-Investigator offers the matching solution for any requirement.

In the assembly SolidWorks is another important tool, that can be connected easily with PCBI via an export and import function: PCB-Investigator even replaces simulated components independently with real SolidWorks parts after exporting.

Pick&Place is a common procedure in assembly and is supported by PCB-Investigator as well, no matter whether it comes to Pick&Place data creation or data base generation.

PCB-Investigator can support or even take work sequences in PCB Fabrication as well.

As en excellent Viewing Tool it highlights important information for any upcoming task like showing hotspots in order to avoid errors and rejects. Another strength of PCB-Investigator is the DFM area: With a wide-ranging Bare Board Analysis (DRC) or by preparing PCB data as high resolution black-white graphics for the AOI, PCB-Investigator helps avoiding costly and time-consuming remanufactures in the first place.

Panel Building for prototype or serial production is another important step. PCB-Investigator can support you optimally with the Panel Builder Plug-In.

Thermal Vias for heat dissipation - the more the better?

This article is dedicated to the question whether more thermal vias automatically ensure a better heat dissipation. Learn how PCB-Investigator Physics can help you answer this question in order for you to make the most efficient and time-saving decision for all your designs!

» Read More

Even in difficult times like these, we are constantly focusing on the further development of our software in order to be able to offer you as our customer the best possible added value.

We therefore now provide you the latest version 11.1 of PCB-Investigator with numerous further developments, optimizations and innovations.

» Read More

Again, this year's major release is based on our constant claim to continuously improve our software according to the latest and highest standards of electronics development and production.

The goal remains the same, always to generate the maximum benefit for our customers! Therefore, the current version offers you numerous new features, plugins and improvements!

» Read More

The newest version of PCB-Investigator 10.6 is out now and offers you some new developments.

» Read More
